PVC/PU belt joint press

General Details

PVC/PU belt joint press, also called the PVC/PU belt hot splicing machine, vulcanizing machine. It is a type of equipment to joint and repair lightweight belts such as PVC, PU, PE belts. By using high temperature, pressure and cooling technology the belts can be well melted and jointed.

Features of PVC/PU belt joint press:

1. Heating plate: lightweight, portable, temperature uniformity;
2. Airbag pressure: adjustable inflatable pressure 0~2.5kg/cm2, easy
to operate. Double-layer structure airbag, designed for long-term use. The charge and discharge mechanism is simple and reliable;
3. Automatic control box: the control box can be pre-set and automatically working according to the setting value, automatic heating, temperature control, temperature holding and start the water cooling. And it has adjustable delay temperature holding function to meet the processing requirements of different belts.
4. Quick water-cooling system: water cooling from 172°C to 60°C, less than 6 minutes;
5. Machine durable structure: steel beam and stainless-steel body, high tensile aluminum alloy plate;

Belt joint press is suitable for the jointing or repairing of light plastic conveyor belts with a pressure below 0.25Mpa and a maximum heating temperature below 195°C.

Technical Info

1. Vulcanization pressure : 0~2.5kg/cm2

2. Vulcanization temperature: 172°C

3. Difference in surface temperature of vulcanized plate: ±5°C

4. Heat up time ( from 60°C to 170°C) : ≤25 minutes

5. Voltage: 110V/220V/380V

6. Maximum vulcanization temperature: <195°C

Product Range

Model

Belt width
(mm)

Specification

Size of heating plate
(L X W) mm

Power
(KW)

Dimension
(L X W X H) mm

Weight
(KG)

Heat up time(min)

Cool  down
time (min)

DLY-300

300

300x150

150x400

3

650x210x190

30

25

2

300x200

200x400

3.4

650x260x190

36

25

2

DLY-400

400

400x150

150x500

3.4

750x210x200

34

25

2

400x200

200x500

3.8

750x260x200

40

25

2

DLY-600

600

600x150

150x700

3.6

950x210x230

50

25

2

600x200

200x700

4.2

950x260x230

62

25

2

DLY-800

800

800x150

150x900

4.2

1150x210x250

65

25

2

800x200

200x900

4.6

1150x260x250

82

25

2

DLY-1000

1000

1000x150

150x1100

4.6

1350x210x300

80

25

2

1000x200

200x1100

5

1350x260x300

96

25

2

DLY-1200

1200

1200x150

150x1300

5

1550x210x300

104

25

2

1200x200

200x1300

5.4

1550x260x300

130

25

2

DLY-1400

1400

1400x150

150x1500

5.4

1750x210x480

120

25

3

1400x200

200x1500

5.8

1750x260x480

150

25

3

DLY-1600

1600

1600x150

150x1700

5.8

1950x210x480

146

25

3

1600x200

200x1700

6.2

1950x260x480

182

25

3

DLY-1800

1800

1800x150

150x1900

6.2

2150x210x480

164

25

3

1800x200

200x1900

6.6

2150x260x480

205

25

3

DLY-2000

2000

2000x150

150x2100

6.6

2350x210x480

185

25

4

2000x200

200x2100

7

2350x260x480

230

25

4

DLY-2200

2200

2200x150

150x2300

7

2550*210*480

200

25

4

2200x200

200x2300

7.4

2550*260*480

250

25

4

DLY-2400

2400

2400x150

150x2500

7.4

2750x210x620

222

25

5

2400x200

200x2500

7.8

2750x260x620

275
