Longitudinal Tear Repair Vulcanizer

General Details

During running of conveyor, due to the reasons of raw material mixing with impurities or conveyor malfunction, conveyor belt will be broken in long distance by longitudinal tear.

DLBRV-III Longitudinal Tear Repair Vulcanizer is specially used to repair longitudinal tear of conveyor belt, it suits for EP, Nylon, Canvas and steel cord belt.

Technical Info

1. Heating plate size: 350*1000 mm

2. Max. Repair size: 250*900 mm

3. Working pressure: 0.5--0.8 MPa

4. Rated power: 5.2 KW

5. Heating up time< 30 minutes

6. Timer adjust range: 0-99 minutes

7. Temperature adjust range: 0-200℃

8. Voltage: 220-660V, 50/60HZ, 3 Phases

9. Repair belt width: 650 mm--2600 mm.


Product Range
  Belt edge repair vulcanizer
Type of conveyor belt Canvas, nylon and steel cord belt
Width range(mm) 650-2600
Maximum size for belt repairing(mm) 250×900
Heating plate size(mm) 350×1000
Vulcanizing temperature 145℃ Adjustable 0—200℃
Total power(Kw) 5.2
Voltage(V) 220-660V, 50/60HZ, 3 Phases
Temperature difference of vulcanized heating plates ±3
Vulcanization pressure(Mpa) 0.5-0.8
Warm up time(min) < 30
